Thermax Babcock & Wilcox Energy Solutions

Range :

Capacity: 1000 TPH to 3175 TPH
Pressure: Subcritical
SH and RH Temperature: Up to 585°C

Benefits:

B&W has extensive worldwide experience in designing, manufacturing, installing and servicing more than 700 Radiant Boilers up to 900 MW.

B&W’s Radiant Boilers, Carolina Type (RBC) and El Paso Type (RBE) incorporate natural circulation which takes advantage of the density difference between water in the down-comers and the steam/water mixture in the furnace tubes to provide cooling flow in these tubes. With natural circulation, no pumps are required, so auxiliary power requirements are reduced and availability is improved.

The RBC is designed to fire pulverized coal. The RBE is designed to fire natural gas and/or oil, blast furnace gas and combustible by-product gases.

Range :

Capacity: No lower or upper limit, largest B&W PGG to date is 4535 TPH
Pressure: Supercritical
SH and RH Temperature: No upper limit, highest to date is 620°C

Benefits :

B&W has extensive worldwide experience in designing, manufacturing, installing and servicing more than 90 supercritical boilers.
B&W installed the first supercritical boiler in the world in 1957 and supplied the largest single unit boiler ever built (1300 MW). 9 such units have been installed by B&W to date.
A spiral furnace design provides better heat transfer and variable pressure operation.

B&W low NOx combustion systems offer an advanced design and rugged construction for proven performance and superior reliability. Our low NOx burner technology has been successfully applied to a broad range of units (more than 132,000 MW; over 9,000 burners) with varying fuel characteristics and boiler arrangements.

DRB-XCL® Low NOx PC-Fired Burner

Benefits:

Proven performance
Superior mechanical reliability and operation
Rugged construction, integrated design
Complete shop assembly, ready for installation
Plug-in design
New or retrofit applications

XCL-S® Low NOx Oil and Gas Burner

Benefits:

Proven performance with more than 11,000 MW of experience
Demonstrated low NOx reductions greater than 90% depending on burner arrangement and equipment supply
Lower CO emissions
Demonstrated low NOx emissions with and without the use of overfire air (OFA) and/or flue gas recirculation (FGR)
Superior flame stability and burner turndown
Improved excess air control
On-line adjustability to optimize performance
Low-cost plug-in design

Dual Air Zone NOx Port (Overfire Air System)

As part of an overall NOx reduction strategy, B&W’s overfire air systems can be combined with other low NOx technologies such as burners and selective catalytic reduction systems.

Benefits:

Dual zone ports for optimized emission reductions
Heavy-duty design well suited for extreme utility boiler conditions
On-line adjustability provides means to minimize NOx emissions

Using an optimized design, reserve capacity and proprietary wear materials, B&W pulverizers set the standard for high availability, reliability and low maintenance.

Type: Vertical, air-swept roll-and-race
Design Features:

Loading system allows independent radial movement of each roller; maintains design performance with up to 40% weight loss of roll wheel tires; stationary or variable speed rotating dual stage classifiers; removable gear drive

Capacity: 15 – 104 TPH

Benefits:

Requires minimal internal inspections
Maintains fineness and capacity throughout the lifespan of the grinding elements
Requires a minimum number of replacement parts
Allows for easy maintenance through a single, large access door
Includes capabilities to manually or automatically change the spring loading and/or coal fineness
Utilizes advanced wear and erosion protection.
Accepts and grinds a wide variety of coal types

Thermax Engineering Construction Company (TECC) is a wholly owned subsidiary of Thermax Limited, offering a full range of field construction and management services for power plant boilers. TECC understands the ground realities of green field projects even in remote territories in India and have the resources and capabilities to meet the challenges of demanding delivery targets while ensuring quality and cost effectiveness. Safety is the guiding principle of the site construction management in order to maintain the highest level of safety and quality during construction. We have a comprehensive Safety Manual and all our activities are controlled by the same.

B&W has always kept pace with the ever-developing steam generation technology and is at the forefront of the world in the state of the art practices. This translates into a huge advantage for our clients as they in turn stay ahead by being able to improve the performance of their existing equipments and plant facilities through our renovation and retrofit services. In the process, they can also significantly extend the life of their equipment.
